GT-3030U 3/8″ Short Lipped Flange (Box of 100)
Box of 100
PRODUCT SUMMARY
These 3/8" drop in Sanko anchors mount into heavy materials like concrete for a semi-flush installation. Box of 100 concrete anchors.
- The most trusted name in core drilling anchors that are 15% stronger than the competition
- Versatile - will work with bolts and threaded rod in any length
- Recessed - drill the hole the same length as the anchor for a flush finish.
- We recommend the use of our setting tool Values shown on the chart are average ultimate values and are offered only as a guide and are not guaranteed.
- A safety factor of 4:1, or 25%, is generally accepted as a safe working load. The concrete compressive strength should be 2,987 psi Inside threads are machine rolled rather than cut for superior holding strength
GT-3030U | Similar to the CT-type anchor, these drop-in anchors are designed with a flanged (lipped) top for semi-flush installation in concrete; each are set exactly the same way with an expansion plug and a setting tool.
Information
Close
BUY ONLINE | Available Now from these Distributors
| Inside Thread | 3/8" |
| Thread Length | 1/2" |
| Outside Diameter x Length | 1/2" x 1-3/16" |
| Drill Bit Diameter | 1/2" |
| Embedment Depth | 1-9/16" |
| Tension Load | 2,867 (lbs) |
| Setting Tool Required | HT-3040 |
| Box Quantity | 100 |
| Carton Quantity | 800 |
