TEC064 Metal Connector Nailer

tec064 metal connector nailer
tec064 metal connector nailer

Summary of Tool

  • Compact design fits between 12” O.C. joists
  • Low nail lockout prevents dry fires
  • Exclusive safety system prevents misfires
  • Exposed nail tip design fires in the hole for faster, more precise nailing
  • Applications include strapping, joist hangers, hurricane ties, rafter ties and connectors, post bases, caps and anchors
Nail Capacity 24
Fastener Length 1-1/2" (38mm) - 2.5" (64mm)
Fastener Diameter .131-.148" (3.33-3.76mm)
Magazine Angle 34°
Collation Paper
Air Inlet 1/4" NPT
Operating Pressure 90-120 PSI (6.2-8.3 bar)
Dimensions 12.6 x 4.45 x 12.17"
(319 x 113 x 309 mm)
Weight 6.83 lbs. (3.1 kg)
